SQL Server 2019 includes new capabilities for data virtualization by extending the Polybase (nicknamed it Polybase++) feature introduced in SQL Server 2016 with the ability to connect to other data sources with client drivers installed:
- SQL Server
- Oracle
- Teradata
- MongoDB
In addition for SQL Server 2019 on Windows, Polybase now supports the ability to connect to any ODBC data source such as MySQL, PostgreSQL, SAP HANA, IBM DB2, or even Excel or Sharepoint.
SQL Server 2019 Polybase still supports connectivity to Hadoop systems as it did in SQL Server 2016 and 2017. In addition. SQL Server 2019 Big Data Clusters provide an integrated data virtualization solution in a Kubernetes cluster.
You will cover the following topics in this Module:
In this module you will learn about the enhanced Polybase feature of SQL Server 2019 designed to meet the needs of the modern data platform.
Organizations often today have multiple database providers and sources that they must integrate together. SQL Server is a leading industry data platform so many customers move data from other data sources into SQL Server often using Extract, Transform, and Load (ETL) applications. ETL applications can be costly to build and maintain and often results in latencies to access data external to SQL Server.
Consider all the data sources a company may have today:
Traditionally, WideWorldImporters would have to write ETL jobs to move data from all these sources into SQL Server. While that solution still may be best for this company, what if SQL Server could act as a "data hub" for all of these sources? What if you could develop T-SQL queries and execute them against SQL Server 2019, and SQL Server would query the external data sources to bring back the results? Imagine if you could join local SQL Server tables with external data sources or perhaps join all of these together!
The questions just asked are in a nutshell what Polybase provides in SQL Server 2019 through a concept called an EXTERNAL TABLE.
External tables are just like SQL Server tables except SQL Server only stores the metadata of the table definition. The data stays where it lives from the external data source. Think of an external table like a view on top of a data source outside of SQL Server. Since an external table is like a table, you can use SQL Server securables to control access to external data sources like you would a local table.
Polybase uses ODBC drivers to connect to sources such as Oracle, Teradata, MongoDB, and SQL Server. And the driver to connect to other SQL Server data sources can be used to connect to Azure SQL Database and Azure SQL Data Warehouse. With SQL Server 2019 on Windows, you can "bring your own driver" and connect to almost any ODBC data source in your environment. Polybase is integrated with the SQL Server engine so the query processor can make smart decisions to "push-down" query predicates instead of streaming back an entire remote table and filtering it locally.
Consider this simple diagram for how external tables work
An application runs a T-SQL query against an EXTERNAL TABLE. The EXTERNAL TABLE is mapped to an EXTERNAL DATA SOURCE which points to the location of the external data source (in this diagram imagine this is Azure SQL Database). SQL Server will take the query against the EXTERNAL TABLE and produce a new query native to the external data source. Results are brought back to SQL Server and produced back to the application.
Polybase has advantages over features like linked servers such as:
- External tables are defined in the database so are naturally part of an Availability Group
- External tables allow you to define your table names per your organization standard vs using object names from the external data source.
- Polybase has built-in scalability through a concept called a scale-out group.
- Polybase has built-in client driver support for Hadoop, Oracle, Teradata, and MongoDB.
You can read more about a comparison of Polybase to Linked Servers at https://docs.microsoft.com/en-us/sql/relational-databases/polybase/polybase-faq?view=sql-server-ver15.
Watch the following video by James-Rowland Jones, Principal Program Manager at Microsoft, explain more about Data Virtualization in SQL Server 2019
Proceed to the Activity to learn an example of how to use Polybase with SQL Server 2019 and Azure SQL Server Database.
In this activity, you will learn how to build an external data source and table to query a table in Azure SQL Database without connecting directly yourself.
NOTE: If at anytime during the Activities of this Module you need to "start over" use the cleanup.sql script and go back to the first activity step in Activity 8.0.
Go through the following steps to learn how to query tables in Azure SQL Database using Polybase.
All scripts for this activity can be found in the sql2019workshop\08_DataVirtualization\sqldatahub\azuredb folder.
IMPORTANT: This activity assumes the following:
- You have installed and enabled Polybase (stand-alone is acceptable) per the documentation at https://docs.microsoft.com/en-us/sql/relational-databases/polybase/polybase-installation?view=sqlallproducts-allversions or for Linux at https://docs.microsoft.com/en-us/sql/relational-databases/polybase/polybase-linux-setup.
- You have access to an Azure SQL Database database or Managed Instance. The T-SQL script createazuredbtable.sql as found in the sql2019lab\04_DataVirtualization\sqldatahub\azuredb directory contains the target schema and data. The scripts in the activity have a specific Azure SQL Database connection string, login, password, and database name (wwiazure). You may need to modify the scripts to match your Azure SQL Database connection, login, password, and db name.
IMPORTANT: For instructor led courses, your instructor will provide you the details of the following authentication and Azure SQL Database Server details. Also, for instructor led courses your instructor has pre-created the Azure SQL Database and objects for this notebook.
STEP 1: Restore the WideWorldImporters backup.
NOTE: If you have restored the WideWorldImporters database backup in other modules, you can skip this step.
Use a tool like SQL Server Management Studio (SSMS) or Azure Data Studio (ADS) to execute the T-SQL script restorewwi.sql as found in the sql2019workshop\08_DataVirtualization folder to restore the WideWorldImporters backup. The script assumes a specific path for the backup and database/log files. You may need to edit this depending on your installation. Remember for Linux installations, the default path is /var/opt/mssql/data. Your instructor may have provided this backup for you but if necessary you can download it from https://github.com/Microsoft/sql-server-samples/releases/download/wide-world-importers-v1.0/WideWorldImporters-Full.bak
STEP 2: Use a T-SQL notebook to connect to Azure SQL Database.
T-SQL notebooks provide a very nice method to execute T-SQL code with documentation in the form of markdown code. All the steps and documentation to complete the rest of the activity for Module 4.0 can be found in the T-SQL notebook azuredbexternaltable.ipynb which can be found in the sql2019workshop\08_DataVirtualization\sqldatahub\azuredb folder.
NOTE: A T-SQL script azuredbexternaltable.sql is also provided if you want to go through the same steps as the notebook but use a tool like SQL Server Management Studio.
CREATE DATABASE SCOPED CREDENTIAL AzureSQLDatabaseCredentials
WITH IDENTITY = '<login>', SECRET = '<password>'
GO
CREATE EXTERNAL DATA SOURCE AzureSQLDatabase
WITH (
LOCATION = 'sqlserver://<azure sql database server URI>',
PUSHDOWN = ON,
CREDENTIAL = AzureSQLDatabaseCredentials
)
GOT-SQL notebooks can be executed with Azure Data Studio. If you are familiar with using Azure Data Studio and T-SQL notebooks open up the azuredbexternaltable.ipynb notebook and go through all the steps. When you are done proceed to the Activity Summary section for the Activity below.
If you have never opened a T-SQL notebook with Azure Data Studio, use the following instructions:
Launch the Azure Data Studio application. Look for the icon similar to this one:
The first time you launch Azure Data Studio, you may see the following choices. For the purposes of this workshop, select No to not load the preview feature and use x to close out the 2nd choice to collect usage data.
You will now be presented with the following screen to enter in your connection details for SQL Server. Use connection details as provided by your instructor to connect to SQL Server or the connection you have setup yourself for your SQL Server instance.
Now click the Connect button to connect. An example of a connection looks similar to this graphic (your server, Auth type, and login may be different):
A successful connection looks similar to this (your server may be different):
If you haven't already used Explorer in Azure Data Studio, it can be used to explore files. Use the power of Azure Data Studio Explorer to open up any file including notebooks. Use the File/Open Folder menu to open up the sql2019workshop folder. Now click the Explorer icon on the left hand side of Azure Data Studio to see all files and directories for the lab. Navigate to the 08_DataVirtualization\sqldatahub\azuredb folder, open up the azuredbexternaltable.ipynb notebook and go through all the steps.
NOTE: Be sure to only run one notebook cell at a time for the lab.
You can now use Azure Data Studio explorer to open up a notebook or script without exiting the tool.
When you start using a notebook and use the "Play" button of a cell, you may get prompted for the connection. Choose the connection you used when you first opened up Azure Data Studio.
There is additional documentation on how to use SQL notebooks at https://docs.microsoft.com/en-us/sql/azure-data-studio/sql-notebooks.
STEP 3: Look at how to connect to other data sources
Look over the scripts and T-SQL notebooks (with saved results) for other data sources in the 08_DataVirtualization\sqldatahub folder. There are subfolders for examples for these data sources:
- Azure CosmosDB (using MongoDB)
- HDFS
- Oracle
- SAP HANA
- SQL Server
- Sharepoint
NOTE: If you want to run these examples, you will need to create or use your own external data source. The scripts and directions to create table definitions, data, and external tables are included.
When you are done proceed to the Activity Summary section for the Activity below.
In this activity you have learned how Polybase in SQL Server 2019 allows you to connect and query data from external data sources without moving data using ETL applications. In the Activity you learned how to create and query an EXTERNAL DATA SOURCE and EXTERNAL TABLE mapped to an Azure SQL Database table.
As an advanced activity go through the steps of the T-SQL script polybasediagnostics.sql as found in the sql2019workshop\08_DataVirtualization\polybasediags folder to see various aspects of using diagnostics with Polybase.
Next, Continue to Big Data Clusters.
